Aurora Performance Racing Series
The Preferred Bearing for Serious Racing
Three-piece Precision Rod Ends
-
Body - 4340 steel, heat treated, protective coated for corrosion resistance
-
Ball - 52100 steel (AMS 7440), heat treated, hard chrome plated
-
Race - stainless steel (17-4 PH per AMS 5643), heat treated, PTFE lined
-
PTFE Liner - (AT 3200) permanently bonded to race inside diameter
| Thread Right |
Thread Left |
B | W | H | A | D | C | N | a | Radial Load,Lbs |
| PRM-5T | PRB-5T | .3125 | .437 | .327 | 1.875 | .900 | 1.187 | 5/16-24 | 14 | 8,300 |
| PRM-6T | PRB-6T | .3750 | .500 | .416 | 1.938 | 1.025 | 1.187 | 3/8-24 | 8 | 10,946 |
| PRM-7T | PRB-7T | .4375 | .562 | .452 | 2.125 | 1.150 | 1.281 | 7/16-20 | 10 | 14,049 |
| PRM-8T | PRB-8T | .5000 | .625 | .515 | 2.438 | 1.337 | 1.468 | 1/2-20 | 9 | 23,310 |
| PRM-10T | PRB-10T | .6250 | .750 | .577 | 2.625 | 1.525 | 1.562 | 5/8-18 | 12 | 25,909 |
| PRM-12T | PRB-12T | .750 | .875 | .640 | 2.875 | 1.775 | 1.687 | 3/4-16 | 13 | 34,319 |
| Right
Heavy Duty |
Left
Large Shank |
|||||||||
| PRXM-4T | PRXB-4T | .250 | .375 | .337 | 1.562 | .806 | .968 | 5/16-24 | 6 | 7,544 |
| PRXM-5T | PRXB-5T | .3125 | .437 | .327 | 1.875 | .900 | 1.187 | 3/8-24 | 14 | 9,135 |
| PRXM-6T | PRXB-6T | .3750 | .500 | .416 | 1.938 | 1.025 | 1.187 | 7/16-20 | 8 | 10,946 |
| PRXM-7T | PRXB-7T | .4375 | .562 | .452 | 2.125 | 1.150 | 1.281 | 1/2-20 | 10 | 14,049 |
| PRXM-8T | PRXB-8T | .500 | .625 | .515 | 2.438 | 1.337 | 1.468 | 5/8-18 | 9 | 23,310 |
| PRXM-10T | PRXB-10T | .6250 | .750 | .577 | 2.625 | 1.525 | 1.562 | 3/4-16 | 12 | 25,909 |
a = angle of misalignment
* Dimensions
in Inches
For Rod End Jam nuts see Fasteners
Aurora Performance Racing Spherical Bearing
| Narrow series |
B |
D |
W |
H |
O |
a |
Radial Load,Lbs | Axial Load,Lbs |
| PNB-5T | .3125 | .750 | .375 | .281 | .419 | 10 | 8,750 | 700 |
| PNB-6T | .3750 | .8125 | .406 | .312 | .475 | 9 | 10,540 | 1,100 |
| PNB-7T | .4375 | .9062 | .437 | .343 | .530 | 8 | 13,200 | 1,400 |
| PNB-8T | .500 | 1.00 | .500 | .390 | .600 | 8 | 17,900 | 2,100 |
| PNB-9T | .5625 | 1.093 | .562 | .437 | .670 | 8 | 23,200 | 3,680 |
| PNB-10T | .6250 | 1.1875 | .625 | .500 | .739 | 8 | 30,500 | 4,720 |
| PNB-12T | .750 | 1.4375 | .750 | .593 | .920 | 8 | 46,400 | 6,750 |
| Wide series | ||||||||
| PWB-5T | .3125 | .6875 | .437 | .317 | .401 | 14 | 9,400 | 1,640 |
| PWB-6T | .3750 | .8125 | .500 | .406 | .466 | 8 | 13,700 | 2,630 |
| PWB-7T | .4375 | .9375 | .562 | .442 | .537 | 10 | 20,700 | 3,650 |
| PWB-8T | .500 | 1.000 | .625 | .505 | .607 | 9 | 21,400 | 4,970 |
| PWB-9T | .5625 | 1.1250 | .687 | .536 | .721 | 10 | 26,600 | 5,370 |
| PWB-10T | .6250 | 1.1875 | .750 | .567 | .747 | 12 | 29,000 | 6,130 |
| PWB-12T | .750 | 1.375 | .875 | .630 | .887 | 13 | 37,000 | 7,730 |
a = angle of misalignment
*Dimensions in
Inches
